Field Description
• +%$( + #: Enables the entry of a range of port
numbers.
Source IPv4 Address/
Netmask
Enter the source IPv4 address of the data packets and the cor-
responding netmask.
Possible values:
• 3( (default value): The source IP address/netmask are not
specified.
• @: Enter the source IP address of the host.
• )79: Enter the source network address and the corres-
ponding netmask.
Source IPv6 Address/
Length
Enter the source IPv6 address of the data packets and the pre-
fix length.
Possible values:
• 3( (default value): The source IP address/length are not
specified.
• @: Enter the source IP address of the host.
• )79: Enter the source network address and the prefix
length.
Source Port/Range
Only if Protocol = *6, .5
Enter a source port number or the range of source port num-
bers.
Possible values:
• 311 (default value): The filter is valid for all port numbers
• +%$( +: Enables the entry of a port number.
• +%$( + #: Enables the entry of a range of port
numbers.
DSCP/TOS Filter
(Layer 3)
Select the Type of Service (TOS).
Possible values:
• # (default value): The type of service is ignored.
• 56 :( E1: Differentiated Services Code Point
according to RFC 3260 is used to signal the priority of IP
packets (indicated in binary format, 6 bit).
10 Networking bintec elmeg GmbH
278 bintec RS Series
