Field Description
setting.
• B) $ 1 %C: Shows a rule chain that has
already been created, which you can select and edit.
Description
Only where Wake-On-LAN Rule Chain = )7
Enter the name of the rule chain.
Wake-On-LAN Filter
Select a WOL filter.
If the rule chain is new, select the filter to be set at the first point
of the rule chain.
If the rule chain already exists, select the filter to be attached to
the rule chain.
To select a filter, at least one filter must be configured in the
Local Services->Wake-On-LAN->WOL Rules menu.
Action
Define the action to be taken for a filtered data packet.
Possible values:
• 9 2-0 $ $1 %: Run WOL if the filter
matches.
• 9 $ $1 %: Run WOL if the fil-
ter does not match.
• 5( 2-0 $ $1 %: Do not run WOL if the fil-
ter matches.
• 5( 2-0 $ $1 %: Do not run
WOL if the filter does not match.
• # 1 9+ ? 1: This rule is ig-
nored and the next one in the chain is examined.
Type Select whether the Wake on LAN magic packet is to be sent as
a UDP packet or as an Ethernet frame via the interface spe-
cified in Send WOL packet over Interface.
Send WOL packet over
Interface
Select the interface which is to be used to send the Wake on
LAN magic packet.
Target MAC-Address
Only where Action = 9 2-0 $ $1
% and 9 $ $1 %
bintec elmeg GmbH
17 Local Services
bintec RS Series 529
