Field Value
also displayed in brackets as a percentage.
ISDN Usage External Shows the number of active B channels and the maximum num-
ber of available B channels for external connections.
Active Sessions (SIF,
RTP, etc... )
Displays the total of all SIF, TDRC, and IP load balancing ses-
sions.
Active IPSec Tunnels Displays the number of currently active IPSec tunnels in relation
to the number of configured IPSec tunnels.
Fields in the Physical Interfaces menu.
Field Value
Interface - Connection
Information - Link
The physical interfaces are listed here and their most important
settings are shown. The system also displays whether the inter-
face is connected or active.
Connection Information for Ethernet interfaces:
• IP address
• Netmask
Connection Information for ISDN interfaces:
• Configured
• Not configured
Connection Information for xDSL interfaces:
• Downstream/Upstream Line Speed
Connection Information for WLAN interfaces:
Access Point Mode:
• Operation Mode: Access Point or Off
• The channel used on this wireless module
• Number of connected clients
• Number of WDS links
• Software version of the wireless card
Connection Information for UMTS/LTE interfaces:
• ' ; appears if no SIM card is inserted.
bintec elmeg GmbH
5 System Management
bintec RS Series 55
