4 Error LED
If there is an error, the error LED will light up red. Check the Settings interface or NAS Navigator2 to see the
error message.
5 LAN1 LED
When LAN port 1 is connected, this LED glows green and blinks when the connection is experiencing activity.
6 LAN2 LED
When LAN port 2 is connected, this LED glows green and blinks when the connection is experiencing activity.
7 Function Button
Use this button for dismounting USB devices, rebuilding RAID arrays, configuring failover, stopping the
TeraStation’s beeping, and initializing settings using a USB drive.
8 Drive Lock ( )
Open the front panel with the key to replace drives or access the init button.
9 Init Button
Press and hold down this button to initialize the TeraStation’s admin username and password, two-factor
authentication settings, IP settings, SSL, and service port restriction settings to their factory default values. The
effects of this button can be changed in Settings.
During initialization, the TeraStation will beep and the I23 message will appear as a notification. When
initialization finishes, the I23 message will disappear.
10 Status LEDs
Normally, these LEDs blink green when drives are accessed. If a drive fails, its LED will turn red.
11 Fan
Spins to prevent overheating inside. Do not block the fan.
12 USB Port ( )
Compatible USB drives, USB memory devices, and USB UPS devices can be connected. USB hubs are not
supported.
13 LAN Port 1 (1GbE, )
Connect an Ethernet cable to use this port for your network. It is available for communicating at max. 1000
Mbps.
14 LAN Port 2 (1GbE, )
Connect an Ethernet cable to use this port for your network. It is available for communicating at max. 1000
Mbps.
15 Power Connector
Use the included power cable to connect to a UPS, surge protector, or outlet.
16 Anti-Theft Security Slot ( )
Use this slot to secure your TeraStation with a cable lock (not included).
17 Serial Number
This sticker shows the TeraStation’s serial number.
18 UID Button
Press this button to cycle the blue LED on and off.
14
Chapter 2 Getting Started
