1 Back up the saved data to another location before replacing the failed drive. If one or more drives fail during

drive replacement, data can no longer be retrieved from the TeraStation.

2 Open the front cover with the included key.

3 The failed drive’s status LED will be glowing red. Push its unlock button and swing the lock mechanism out.

4 Pull out the drive cartridge and remove it from the TeraStation.

5 Insert the new drive into the empty slot with the lock mechanism remaining open.

6 Swing the lock back down until it clicks into place.

7 Press the power button on the TeraStation.

8 When the replaced drive is recognized, the status LED will flash red and the I32 message will appear as a

notification.

9 Close the front cover.

10 From Settings, navigate to Storage> RAID.

11 Click the RAID array that held the failed drive, then select the replaced drive and click Recover RAID Array.

12 The RAID array recovery will begin. The I18 message will appear as a notification after a few minutes. The

process is complete when the I18 message disappears.

Drive Replacement for a RAID 0 Array

If a drive used in a RAID 0 array fails, you need to delete the RAID array, format the replaced drive, then create a RAID

0 array again after replacing the defective drive to a new drive.

Note: If a drive malfunctions in a RAID 0 array, all data on the RAID array will be lost. All of the settings for the shared

folders (such as access restrictions) are erased after replacing a drive from a RAID 0 array.

1 Turn off the TeraStation.
