SECTION 31 - IMPLEMENT POWER TAKE-OFF (PTO) - CHAPTER 3
31-2
OVERRUNNING CLUTCH
Overrunning Clutch - Disassembly
If the overrunning clutch does not operate when the
tractor PTO is disengaged, the overrunning clutch
must be disassembled for inspection. Remove the
slip clutch from the unit as previously described. It is
possible to repair the overrunning clutch without
disassembling the slip clutch.
1. Turn out the four cap screws, 1, holding the
overrunning clutch to the slip clutch housing.
1
1
50006847
1
2. Pry out the snap ring, 1, and lift off the washer, 2,
from the hub of the overrunning clutch.
2
1
50006848
2
