SECTION 00 - GENERAL INFORMATION - CHAPTER 3
00-9
TONGUE PIVOT PIN
Fitting, 1, (4 -- 6 pumps)
20011825
1
16
WHEEL BEARINGS
Repack the wheel bearings every 400 hours or each
season with premium grease EP-2.
19982129
1
17
CUTTER BAR MOUNTING BOLTS
Fittings, 1, left and right cutter bar mounting bolts (one
fitting on each bolt, four bolts total.) (4 -- 6 pumps)
WARNING
Disengage the PTO, turn off the tractor engine
and remove the key. Wait for all movement to
stop before leaving operator’s position. Never
adjust, lubricate, clean or unplug machine with
the engine running. Failure to comply could
result in death or serious injury.
19991341
1
18
