SECTION 31 - IMPLEMENT POWER TAKE-OFF (PTO) - CHAPTER 1
31-15
8. Slide the female shaft over the male shaft.
86065260
36
9. Align the grease fitting, 1, with the square notch
cut out of the guard. Secure the guard to the
support ring with screws.
86065244
1
37
Secondary PTO Disassembly
1. At either end, unscrew the screws, 1, holding the
shield, cone shield, and support ring together.
86065255
1
38
