SECTION 31 - IMPLEMENT POWER TAKE-OFF (PTO) - CHAPTER 1
31-16
At this point, you can now slide the two shafts apart.
2. Slide the cone shield, 1, off of the support ring.
86065256
1
39
3. Spread apart the support ring, 1, and remove it
from the groove.
86065257
86065258
1
40
On the opposite end of the PTO.
4. Remove the screws.
86065262
41
