SECTION 00 - GENERAL INFORMATION - CHAPTER 2
00-2
CONDITIONING (ROLL PRESSURE)
Adjust the roll pressure with crank, 1. Turn crank
clockwise to increase the roll pressure. Apply only
sufficient pressure to crack the stems, with minimal
damage to the leaves. Overconditioning will result in
leaves overdrying and shattering, increased power
requirements, and increased driveline wear.
Relatch the handle clip into retainer notch, 2.
A3658-3
1
2
1
UNPLUGGING THE CONDITIONER ROLLS
1. If the conditioner rolls plug or wrap with crop, the
slip clutch should operate to protect the driveline.
Stop the forward movement of the tractor and
shut off the PTO.
NOTE: The slip clutch will be damaged if it is slipped
for more than a few seconds.
2. Raise the header, back up away from the uncut
crop, engage the transport stops. Shut off the
tractor engine and lock brakes.
3. Clean material off the cutter bar.
4. Relieve roll pressure by turning the adjustment
crank clockwise, and pull as much material as
possible from the front and behind the rolls.
WARNING
Do not attempt to unplug conditioner rolls without
first relieving roll pressure. Roll pressure could
cause top conditioner roll to move downward
suddenly and could cause death or serious injury.
