SECTION 00 - GENERAL INFORMATION - CHAPTER 3
00-5
EVERY 50 HOURS
Lubricate the slide collar, 2, as required with oil to
prevent rust from seizing the components.
BONDIOLI PRIMARY PTO -- EVERY 50
HOURS
Fittings, 1, universal joints (2 fittings) (4 -- 6 pumps)
540 and 1000 rpm.
Fitting, 2, sliding PTO shaft, 4, (1 fitting) (16 -- 20
pumps) 540 and 1000 rpm.
NOTE: Make certain the grease is spread over the
two entire lengths of the shaft.
Fitting, 3, CV center housing (1 fitting) (16 -- 20
pumps) 540 and 1000 rpm.
86064447
2
3
4
1
4
NOTE: It may be necessary to remove the PTO from
the tractor to access fitting, 3.
86064448
3
1
5
Lubrication is extremely important to this CV joint.
The grease paths are shown for the above fittings.
NOTE: Some resistance may be felt when adding
lubricant at fitting, 4. Ensure 16 -- 20 pumps of grease
are used.
86064449
3
1
1
6
