SECTION
31
-
IMPLEMENT
POWER
T
AKE
-
OFF
(PT
O)
-
CHAPTER
3
31-7
SLIP
W
ITH
O
VERRUNNING
CLUTCH
Disassembly
1.
Remove
the
grease
fitting,
1.
2.
Break
loos
e
the
eight
nuts
,
2.
Loosen
and
remove
the
nu
ts.
8606526
9
1
11
3.
Remove
the
Bellev
ille
Spring,
1.
8606526
9
1
12
4.
Lightly
tap
the
bolts
with
a
hammer
to
loosen
them
from
the
clutch
as
sembly
.
8606526
9
13
104
106
