SECTION 00 - GENERAL INFORMATION - CHAPTER 3
00-7
Telescoping Section
Fitting, 1, sliding PTO shaft (16 -- 20 pumps)
WARNING
Disengage the PTO, turn off the tractor engine
and remove the key. Wait for all movement to
stop before leaving operator’s position. Never
adjust, lubricate, clean or unplug machine with
the engine running. Failure to comply could
result in death or serious injury.
1411-18
1
10
Rear CV Joint and Slip Clutch Assembly
Fittings, 1, universal joints (2 fittings) (4 -- 6 pumps)
Fitting, 2, CV inner yoke flange (16 -- 20 pumps)
86064450
2
1
11
Fitting, 3, overrunning clutch (2 pumps)
NOTE: Excessive greasing of the overrunning clutch
will cause grease to migrate into the clutch plates and
permit the clutch to slip prematurely.
86064451
3
12
