SECTION 00 - GENERAL INFORMATION - CHAPTER 1
00-19
TRANSPORTING THE MOWER-CONDITIONER
SLOW-MOVING VEHICLE EMBLEM
Some states and provinces require Slow-Moving
Vehicle (SMV) emblems on machines traveling at
speeds under 40 km/hr (25 MPH). Consult local
regulations for information and mounting require-
ments.
A SMV mounting bracket, 1, is located on the left rear
frame. The SMV emblem, 2, and mounting bracket
are furnished as standard equipment on the
mower-conditioner. Attach the emblem as shown.
TRANSPORTING ON HIGHWAYS
Do not tow equipment that does not have brakes:
• At speeds over 32 km/hr (20 MPH) or
• That when fully loaded, weighs more than 1.5 t
(3300 lbs) and more than 1.5 times the weight of
the towing unit.
50011809
2
1
10
SAFETY CHAIN
The optional safety chain, 1, shown should be used
when towing the mower-conditioner on a public road.
The safety chain is intended to keep the machine
under control in the event of loss or failure of the hitch
pin.
When the chain is attached to the tractor it should be
supported midway between the machine and tractor.
A clevis should be installed on the drawbar to support
the chain.
WARNING
You must always hook up the safety chain to the
tractor when towing this machine. Failure to
comply will result in death or serious injury.
1411-01r
1
11
