INTRODUCTION
The disc mower-conditioner is equipped with two 2.6
m (102″-long) steel or rubber conditioner rolls, 1, to
condition the crop thoroughly, yet gently, for fast
drying without leaf loss or crop damage. Cut crop is
fed directly from the cutter bar into the conditioner
rolls. The conditioner rolls are adjustable for
clearance, pressure and timing.
20011819
1
1
The conditioner rolls are driven from the bevel
gearbox, 1, through a 4HB banded belt, 2, to the
conditioner drive gearbox, 3.
