Case IH DCX101 - Page 104

SECTION 31 - IMPLEMENT POWER TAKE-OFF (PTO) - CHAPTER 3
31-6
1
2
10
3
4
4
5
4
6
7
8
9
11
4
12
13
14
16
17
15
10
Exploded view of the Slip with Overrunning Clutch
Assembly.
1. Bolt
2. Flange Yoke
3. Adjustment Band
4. Friction Lining
5. Driving Plate
6. Inner Plate
7. Locking Plate
8. Allen Bolt
9. Overrunning Clutch Plug
10. Overrunning Clutch Housing
11. Grease Fitting
12. Pressure Plate
13. Belleville Spring
14. Snap Ring
15. Key and Spring Kit
16. Hub
17. Tapered Pin
