SECTION 31 - IMPLEMENT POWER TAKE-OFF (PTO) - CHAPTER 3
31-5
4. Apply a film of grease to the pawls, 1, and set
each in place on top of the leaf springs.
1
50006854
8
5. Slide the hub, 1, over the pawls. Secure the hub
in place with the washer, 2, and snap ring, 3.
6. Install the slip clutch as previously described.
2
3
50006848
1
9
