4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 6-13
BOOT HOST Set KB not accessible Cause: Hardware
issue
Remedy: Clear
alarms, reset unit,
and notify customer
service if the problem
persists.
KB is not
detected by Boot
code.
Major
LCD not connected LCD is not
detected by Boot
code.
FLASH Not Found Flash memory
not detected.
EMI SDRAM Test
Failed
RAM Failure -
memory testing
failed.
BOOT Invalid Boot SW cannot
be read from
memory
correctly.
FPGA Invalid FPGA Image
cannot be read
from memory
correctly.
APP Invalid Application SW
cannot be read
from memory
correctly.
Clear BOOT passed
Boot Secondary Set FLASH Not Found Cause: Hardware
issue.
Remedy: Clear
alarms, reset the unit,
and notify customer
service if the problem
persists.
Flash memory
not detected.
Major
EMI SDRAM Test
Failed
RAM Failure -
memory testing
failed.
BOOT Invalid Boot SW cannot
be read from
memory
correctly.
FPGA Invalid FPGA Image
cannot be read
from memory
correctly.
Alarm Message
Type
Message Cause/Remedy Description Severity

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
