COBHAM GR712RC User Manual

GR712RC-UM, Jun 2017, Version 2.9 26 www.cobham.com/gaisler
GR712RC
164 SWMX[47] TCD[3] - In Telecommand Data 3
GPIO[44] - In GPIO 2 Register, bit 12 (input only)
163 SWMX[48] SDCASN Low High-Z Out SDRAM Column Address Strobe
GPIO[45] - High-Z In/Out GPIO 2 Register, bit 13
162 SWMX[49] SDRASN Low High-Z Out SDRAM Row Address Strobe
GPIO[46] - High-Z In/Out GPIO 2 Register, bit 14
161 SWMX[50] TCACT[3] High In Telecommand Active 3
GPIO[47] - In GPIO 2 Register, bit 15 (input only)
160 SWMX[51] SPIMISO In SPI Master In Slave Out
TCRFAVL[3] High In Telecommand RF Available 3
SLI - In SLINK Data In
GPIO[48] - In GPIO 2 Register, bit 16 (input only)
157 SWMX[52] SDWEN Low High-Z Out SDRAM Write Enable
GPIO[49] - High-Z In/Out GPIO 2 Register, bit 17
155 SWMX[53] SDDQM[2] High High-Z Out SDRAM Data Mask 2, corresponds to
DATA[23:16]
GPIO[50] - High-Z In/Out GPIO 2 Register, bit 18
154 SWMX[54] SDDQM[3] High High-Z Out SDRAM Data Mask 3, corresponds to
DATA[31:24]
GPIO[51] - High-Z In/Out GPIO 2 Register, bit 19
153 SWMX[55] TCACT[4] High In Telecommand Active 4
GPIO[52] - In GPIO 2 Register, bit 20 (input only)
144 SWMX[56] TCRFAVL[4] High In Telecommand RF Available 4
GPIO[53] - In GPIO 2 Register, bit 21 (input only)
143 SWMX[57] I2CSDA High-Z In/Out I2C Serial Data
GPIO[54] - High-Z In/Out GPIO 2 Register, bit 22
TCCLK[4] Rising In Telecommand Clock 4
142 SWMX[58] I2CSCL High-Z In/Out I2C Serial Clock
GPIO[55] - High-Z In/Out GPIO 2 Register, bit 23
TCD[4] - In Telecommand Data 4
140 SWMX[59] CB[8] - High-Z In/Out Reed-Solomon Check Bit 8
GPIO[56] - High-Z In/Out GPIO 2 Register, bit 24
137 SWMX[60] CB[9] - High-Z In/Out Reed-Solomon Check Bit 9
GPIO[57] - High-Z In/Out GPIO 2 Register, bit 25
136 SWMX[61] CB[10] - High-Z In/Out Reed-Solomon Check Bit 10
GPIO[58] - High-Z In/Out GPIO 2 Register, bit 26
135 SWMX[62] CB[11] - High-Z In/Out Reed-Solomon Check Bit 11
GPIO[59] - High-Z In/Out GPIO 2 Register, bit 27
132 SWMX[63] CB[12] - High-Z In/Out Reed-Solomon Check Bit 12
GPIO[60] - High-Z In/Out GPIO 2 Register, bit 28
129 SWMX[64] CB[13] - High-Z In/Out Reed-Solomon Check Bit 13
GPIO[61] - High-Z In/Out GPIO 2 Register, bit 29
128 SWMX[65] CB[14] - High-Z In/Out Reed-Solomon Check Bit 14
GPIO[62] - High-Z In/Out GPIO 2 Register, bit 30
127 SWMX[66] CB[15] - High-Z In/Out Reed-Solomon Check Bit 15
GPIO[63] - High-Z In/Out GPIO 2 Register, bit 31
Table 6. I/O switch matrix pin description, defining the order of priority for outputs and input/outputs, with the highest
priority for each pin listed first.
Pin no. Pin name Pin function Polarity Reset value Dir. Description
