COBHAM GR712RC User Manual

GR712RC-UM, Jun 2017, Version 2.9 28 www.cobham.com/gaisler
GR712RC
202 SWMX[21] SPW_TXD[3] High High-Z Out SpaceWire Transmit Data 3
203 SWMX[20] SPW_TXS[3] High High-Z Out SpaceWire Transmit Strobe 3
225 SWMX[15] SPW_RXD[4] High In SpaceWire Receive Data 4
226 SWMX[14] SPW_RXS[4] High In SpaceWire Receive Strobe 4
227 SWMX[13] SPW_TXD[4] High High-Z Out SpaceWire Transmit Data 4
228 SWMX[12] SPW_TXS[4] High High-Z Out SpaceWire Transmit Strobe 4
192 SWMX[27] SPW_RXD[5] High In SpaceWire Receive Data 5
193 SWMX[26] SPW_RXS[5] High In SpaceWire Receive Strobe 5
197 SWMX[24] SPW_TXD[5] High High-Z Out SpaceWire Transmit Data 5
196 SWMX[25] SPW_TXS[5] High High-Z Out SpaceWire Transmit Strobe 5
178 SWMX[37] SpaceWire clock
divisor registers
values at reset, all
other bits are zero.
- In At reset, bits 8 & 0 are set from this input
175 SWMX[40] - In At reset, bits 9 & 1 are set from this input
172 SWMX[43] - In At reset, bits 10 & 2 are set from this input
166 SWMX[45] - In At reset, bits 11 & 3 are set from this input
185 SWMX[32] RMTXEN High High-Z Out Ethernet Transmit Enable
191 SWMX[28] RMTXD[0] - High-Z Out Ethernet Transmit Data 0
190 SWMX[29] RMTXD[1] - High-Z Out Ethernet Transmit Data 1
189 SWMX[30] RMRXD[0] - In Ethernet Receive Data 0
188 SWMX[31] RMRXD[1] - In Ethernet Receive Data 1
183 SWMX[34] RMCRSDV High In Ethernet Carrier Sense / Data Valid
182 SWMX[35] RMINTN Low In Ethernet Management Interrupt
179 SWMX[36] RMMDIO - High-Z In/Out Ethernet Media Interface Data
178 SWMX[37] RMMDC - High-Z Out Ethernet Media Interface Clock
177 SWMX[38] RMRFCLK - In Ethernet Reference Clock
220 SWMX[16] CANTXA - High-Z Out CAN Transmit A
218 SWMX[18] CANRXA - In CAN Receive A
219 SWMX[17] CANTXB - High-Z Out CAN Transmit B
217 SWMX[19] CANRXB - In CAN Receive B
191 SWMX[28] - High-Z Out Proprietary, enabled by CAN
190 SWMX[29] - High-Z Out Proprietary, enabled by CAN
185 SWMX[32] - High-Z Out Proprietary, enabled by CAN
184 SWMX[33] - High-Z Out Proprietary, enabled by CAN
172 SWMX[43] - High-Z Out Proprietary, enabled by CAN
177 SWMX[38] 1553CK - In MIL-STD-1553B Clock
184 SWMX[33] 1553TXINHA High High-Z Out MIL-STD-1553B Transmit Inhibit A
190 SWMX[29] 1553TXA High High-Z Out MIL-STD-1553B Transmit Positive A
185 SWMX[32] 1553TXNA Low High-Z Out MIL-STD-1553B Transmit Negative A
191 SWMX[28] 1553RXENA High High-Z Out MIL-STD-1553B Receive Enable A
189 SWMX[30] 1553RXA High In MIL-STD-1553B Receive Positive A
188 SWMX[31] 1553RXNA Low In MIL-STD-1553B Receive Negative A
174 SWMX[41] 1553TXINHB High High-Z Out MIL-STD-1553B Transmit Inhibit B
178 SWMX[37] 1553TXB High High-Z Out MIL-STD-1553B Transmit Positive B
175 SWMX[40] 1553TXNB Low High-Z Out MIL-STD-1553B Transmit Negative B
179 SWMX[36] 1553RXENB High High-Z Out MIL-STD-1553B Receive Enable B
183 SWMX[34] 1553RXB High In MIL-STD-1553B Receive Positive B
182 SWMX[35] 1553RXNB Low In MIL-STD-1553B Receive Negative B
143 SWMX[57] I2CSDA High-Z In/Out I2C Serial Data
142 SWMX[58] I2CSCL High-Z In/Out I2C Serial Clock
169 SWMX[44] SPICLK High-Z Out SPI Clock
166 SWMX[45] SPIMOSI - High-Z Out SPI Master Out Slave In
160 SWMX[51] SPIMISO In SPI Master In Slave Out
Table 7. I/O switch matrix pins listed per function, including supporting signals outside the I/O switch matrix.
