COBHAM GR712RC User Manual

GR712RC-UM, Jun 2017, Version 2.9 29 www.cobham.com/gaisler
GR712RC
203 SWMX[20] SLSYNC High High-Z Out SLINK SYNC
166 SWMX[45] SLCLK High High-Z Out SLINK Clock
160 SWMX[51] SLI - In SLINK Data In
169 SWMX[44] SLO - High-Z Out SLINK Data Out
226 SWMX[14] A16DASA - In ASCS DAS A - Slave data in
225 SWMX[15] A16DASB - In ASCS DAS B - Slave data in
202 SWMX[21] A16ETR High High-Z Out ASCS ETR - Synchronization signal
175 SWMX[40] A16DCS - High-Z Out ASCS DCS - Slave data out
174 SWMX[41] A16MAS High High-Z Out ASCS MAS - TM start/stop signal
179 SWMX[36] A16MCS High High-Z Out ASCS MCS - TC start/stop signal
178 SWMX[37] A16HS High High-Z Out ASCS HS - TM/TC serial clock
229 SWMX[11] TCACT[0] High In Telecommand Active 0
226 SWMX[14] TCCLK[0] Rising In Telecommand Clock 0
225 SWMX[15] TCD[0] - In Telecommand Data 0
193 SWMX[26] TCRFAVL[0] High In Telecommand RF Available 0
188 SWMX[31] TCACT[1] High In Telecommand Active 1
192 SWMX[27] TCCLK[1] Rising In Telecommand Clock 1
189 SWMX[30] TCD[1] - In Telecommand Data 1
183 SWMX[34] TCRFAVL[1] High In Telecommand RF Available 1
176 SWMX[39] TCACT[2] High In Telecommand Active 2
182 SWMX[35] TCCLK[2] Rising In Telecommand Clock 2
177 SWMX[38] TCD[2] - In Telecommand Data 2
173 SWMX[42] TCRFAVL[2] High In Telecommand RF Available 2
161 SWMX[50] TCACT[3] High In Telecommand Active 3
165 SWMX[46] TCCLK[3] Rising In Telecommand Clock 3
164 SWMX[47] TCD[3] - In Telecommand Data 3
160 SWMX[51] TCRFAVL[3] High In Telecommand RF Available 3
153 SWMX[55] TCACT[4] High In Telecommand Active 4
143 SWMX[57] TCCLK[4] Rising In Telecommand Clock 4
142 SWMX[58] TCD[4] - In Telecommand Data 4
144 SWMX[56] TCRFAVL[4] High In Telecommand RF Available 4
231 SWMX[9] TMCLKI Rising In Telemetry Clock Input
230 SWMX[10] TMCLKO - High-Z Out Telemetry Clock Output
232 SWMX[8] TMDO - High-Z Out Telemetry Data Out
Table 7. I/O switch matrix pins listed per function, including supporting signals outside the I/O switch matrix.
