4.2.10 Exceptions
LEON3 adheres to the general SPARC V8 trap model. The table below shows the implemented traps
and their individual priority. When PSR (processor status register) bit ET=0, an exception trap causes
the processor to halt execution and enter error mode, and the external error signal will then be
asserted.
4.2.11 Single vector trapping (SVT)
Single-vector trapping (SVT) is an SPARC V8e option to reduce code size for embedded applications.
When enabled, any taken trap will always jump to the reset trap handler (%tbr.tba + 0). The trap type
will be indicated in %tbr.tt, and must be decoded by the shared trap handler. SVT is enabled by setting
bit 13 in %asr17.
Table 15. Trap allocation and priority
Trap TT Pri Description
reset 0x00 1 Power-on reset
write error 0x2b 2 write buffer error
instruction_access_error 0x01 3 Error during instruction fetch
illegal_instruction 0x02 5 UNIMP or other un-implemented instruction
privileged_instruction 0x03 4 Execution of privileged instruction in user mode
fp_disabled 0x04 6 FP instruction while FPU disabled
cp_disabled 0x24 6 CP instruction while Co-processor disabled
watchpoint_detected 0x0B 7 Hardware breakpoint match
window_overflow 0x05 8 SAVE into invalid window
window_underflow 0x06 8 RESTORE into invalid window
register_hadrware_error 0x20 9 Uncorrectable register file EDAC error
mem_address_not_aligned 0x07 10 Memory access to un-aligned address
fp_exception 0x08 11 FPU exception
data_access_exception 0x09 13 Access error during load or store instruction
tag_overflow 0x0A 14 Tagged arithmetic overflow
divide_exception 0x2A 15 Divide by zero
interrupt_level_1 0x11 31 Asynchronous interrupt 1
interrupt_level_2 0x12 30 Asynchronous interrupt 2
interrupt_level_3 0x13 29 Asynchronous interrupt 3
interrupt_level_4 0x14 28 Asynchronous interrupt 4
interrupt_level_5 0x15 27 Asynchronous interrupt 5
interrupt_level_6 0x16 26 Asynchronous interrupt 6
interrupt_level_7 0x17 25 Asynchronous interrupt 7
interrupt_level_8 0x18 24 Asynchronous interrupt 8
interrupt_level_9 0x19 23 Asynchronous interrupt 9
interrupt_level_10 0x1A 22 Asynchronous interrupt 10
interrupt_level_11 0x1B 21 Asynchronous interrupt 11
interrupt_level_12 0x1C 20 Asynchronous interrupt 12
interrupt_level_13 0x1D 19 Asynchronous interrupt 13
interrupt_level_14 0x1E 18 Asynchronous interrupt 14
interrupt_level_15 0x1F 17 Asynchronous interrupt 15
trap_instruction 0x80 - 0xFF 16 Software trap instruction (TA)
