ComAp InteliDrive Lite Reference Guide

InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
57
State
Condition of the transition
Action
Next state
OFF mode selected or Shut down alarm
active
Not Ready
Not Ready
RPM < 2, Oil pressure not detected, D+
not Active, no shutdown alarm active,
other than OFF mode selected
Ready
Prestart
1
Prestart time elapsed
STARTER on
FUEL SOLENOID on
2
MaxCrank time counter
started
Cranking
Cranking
1
RPM > Start RPM AND BI: Nominal/Idle
is active
STARTER off
PRESTART off
Starting
RPM > Start RPM AND BI: Nominal/Idle
is not active
STARTER off
PRESTART off
READY TO LOAD on
Running
D+ input activated for 1s or oil pressure
detected
STARTER off
PRESTART off
Cranking
MaxCrank time elapsed, 1st attempt
STARTER off
FUEL SOLENOID off
STOP SOLENOID on
CrankFail pause timer started
Crank pause
MaxCrank time elapsed, last attempt
STARTER off
PRESTART off
Shutdown (Start
fail)
Crank
pause
1
CrankFail pause elapsed
STARTER on
FUEL SOLENOID on
2
STOP SOLENOID off
MaxCrank time counter
started
Cranking
Starting
1
BI: Nominal/Idle is active
FUEL SOLENOID on
2
STOP SOLENOID off
READY TO LOAD off
Starting
RPM = 0 or any other shutdown
condition
FUEL SOLENOID off
STOP SOLENOID on
Shutdown
60 sec. Elapsed
FUEL SOLENOID off
STOP SOLENOID on
Shutdown (Start
fail)
Running
Stop request
READY TO LOAD off
Cooling time timer started
Cooling
