CDM-840 Remote Router MN-CDM840
Ethernet-based Remote Product Management Revision 3
6–82
• Set Time (hh:mm:ss) – Use the HH:MM:SS time format to set the time, where HH=hour [00-
23]; MM=minutes [00-59]; and SS=seconds [00-59].
• Set Date (dd/mm/yy) – Use the DD/MM/YY European time format to set the date, where
DD=day [01-31]; MM=month [01-12]; and YY=year [00-99].
Click [Submit] to save.
• Adjustment for Internal 10 MHz Reference (-999 to +999) – Enter a value to set the
adjustment for the Internal 10 MHz High Stability Reference.
Click [Submit] to save.
Save/Load Configuration
This section allows you to save, and then load (recall) up to 10 configuration sets:
• To save a configuration set:
o First, adjust all operational configuration parameters to suit.
o Then, use the top (Save) Select Location drop-down to select 1 through 10.
o Finally, click [Save Configuration] to store the configuration set.
• To load (recall) a configuration set:
o First, use the bottom (Load) Select Location drop-down to select 1 through 10.
o Then, click [Load Configuration] to recall the selected configuration set.
BERT (Bit Error Rate Test)
CAUTION – Enabling BERT will disrupt any messaging in use (ACM, ECM, VMS, CDRP,
ARP) across the Advanced VSAT Network! This may result in a negative impact on
the operation of the network!
• Tuner Select – Use the drop-down list select the active tuner (demodulator). Depending on
the chassis configuration, the minimum selection is 1 or 2; the maximum is from 1 to 12.
Click [Submit Changes] when done. Any further BERT configuration or operational settings
will apply to the selected tuner.
BERT Config
• Configure the Rx BERT State as On or Off.
• Configure the Rx BERT Pattern as 2^23-1 (2
23
-1) or 2047.
