Comtec CDM-840 - Page 195

CDM-840 Remote Router MN-CDM840
Serial-based Remote Product Management Revision 3
7–27
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
Management
MAC Address
N/A
12 bytes,
alphanumeric
Query only.
Returns the unique FE management port MAC Address in the form
xx:xx:xx:xx:xx:xx
EXAMPLE: <0/MAC?[cr]
>0000/MAC=00:06:B0:00:01:C2[cr][lf]
N/A
MAC?
MAC=xx:xx:xx:xx:xx:xx
(see Description of
Arguments)
GE MAC
Address
N/A
12 bytes,
alphanumeric
Query only.
Returns the unique GE traffic port MAC Address in the form xx:xx:xx:xx:xx:xx
EXAMPLE: <0/MG1?[cr]
>0000/MG1=00:06:B0:00:01:C2[cr][lf]
N/A
MG1?
MG1= xx:xx:xx:xx:xx:xx
(see Description of
Arguments)
Management
Link
Configuration
MLC=
1 byte
Command or Query.
Sets or returns 10/100 BaseT Fast Ethernet FE Management port Interface
Mode in the form x, where:
0=Auto Negotiate
1=reserved
2=100 Mbps Full Duplex
3=100 Mbps Half Duplex
4=10 Mbps Full Duplex
5=10 Mbps – Half Duplex
EXAMPLE: <0/MLC=3[cr]
MLC =
MLC?
MLC *
MLC #
MLC?
MLC =x
(see Description of
Arguments)
Actual
Negotiated
Port Speed
N/A
None
Query only.
Returns actual negotiated port speed in the form ab, where:
a=GE traffic port negotiated port speed.
b=FE management port negotiated port speed.
‘a’ and ‘b’ have the following values:
0=Link down
1=100 Full Duplex
2=100 Half Duplex
3=10 Full Duplex
4=10 Half Duplex
5=1000 Full Duplex
EXAMPLE: <0/NPS?[cr]
>0000/NPS=2[cr][lf]
N/A
NPS?
NPS=ab
(see Description of
Arguments)
