CDM-840 Remote Router MN-CDM840
Serial-based Remote Product Management Revision 3
7–26
Parameter
Type
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to Query
(Target to Controller)
WWWW=hex representation of the weeks field (weeks since 1/6/1980)
SSSSSSSS=hex representation of the seconds field (seconds this week)
FFFFFFFF=hex representation of the Tx frequency
BBBBBBBB=hex representation of the Tx symbol rate
M=bitmap for exclusion setting from user, and if locked from the router bit,
where:
0=lock bit
1=exclusion bit
AAAA=Latitude from user input
OOOOO=Longitude from user input
NNNNNNNN=Satellite naming string (from 1 to 8 characters)
Sets or returns the IP Address and network prefix for the 10/100 BaseT
Ethernet Traffic port, in the form xxx.xxx.xxx.xxx/yy, where:
xxx.xxx.xxx.xxx=the IP Address
yy=the network prefix (8-30)
EXAMPLE: <0/IG1=192.168.001.004/24[cr]
(see Description
of Arguments)
Returns active software image in the form x, where:
1=Bulk Image #1 currently active
2=Bulk Image #2 currently active
EXAMPLE: <0/IMG?[cr]
(see Description of
Arguments)
Sets or returns the IP Address and network prefix for the 10/100 BaseT Fast
Ethernet FE Management port, in the form xxx.xxx.xxx.xxx/yy, where:
xxx.xxx.xxx.xxx=the IP Address
yy=the network prefix (8-30)
EXAMPLE: <0/IPG=192.168.001.004/24[cr]
(see Description
of Arguments)
Sets or returns the 10/100/1000 BaseT Gigibit Ethernet GE traffic port
Interface Mode in the form x, where:
0=Auto Negotiate
1=1000 Mbps Full Duplex
2=100 Mbps Full Duplex
3=100 Mbps Half Duplex
4=10 Mbps Full Duplex
5=10 Mbps Half Duplex
(see Description of
Arguments)
