CDM-840 Remote Router MN-CDM840
Appendix J Revision 3
J–9
3. Configure the Max/Pri QoS rules as follows:
Index
VLAN
Range
TOS Protocol
Src IP/
Mask
Dest
IP/
Mask
Min
Src
Port
Max
Src
Port
Min
Dst
Port
Max
Dst
Port
Max
BW
(kbps)
Priority WRED
Filter
All
1
0-4094
255
UDP
***/*
***/*
0
65535
0
65535
644
1
N
N
2
0-4094
255
TCP
***/*
***/*
0
65535
0
65535
99999
2
N
N
3
0-4094
255
HTTP
***/*
***/*
0
65535
0
65535
99999
3
N
N
4
0-4094
255
Def
****/*
***/*
0
65535
0
65535
99999
9
N
N
When using the Add/Delete Per Group QoS Rule table, note that QoS Rules match
from left to right, with the VLAN Range being the highest match, and the Destination
Port range being the lowest match. Matches can be made using multiple attributes.
4. The input data streams are as follows:
Stream
VLAN
Range
TOS Protocol
Src
IP/Mask
Dest
IP/Mask
Src Port Dest Port
Stream Data
Rate (kbps)
1
0-4094
255
UDP
***/*
***/*
***
***
1024
2
0-4094
255
TCP
***/*
***/*
***
***
1024
3
0-4094
255
HTTP
***/*
***/*
***
***
1024
4
0-4094
255
IP
***/*
***/*
***
***
64
QUESTION: What are the total output data rates and the individual stream data rates?
ANSWER: The individual stream data rates are as follows:
QoS
Rule
QoS Group
Priority
Input Data Rate
(kbps)
QoS Output Data Rate
(kbps)
Remain Data Rate (kbps)
(After Serving the Priority Queue)
1
1
1024
644 due to max clipping
1404
2
2
1024
1024
380
3
3
1024
380
0
4
9
64
0
0
Total ►
3136
2048
0
