CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Serial-based Remote Product Management 8–32 MN-CDM570A
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
Request to Send
RTS=
1 byte,
value of 0 thru 3
Command or Query.
Sets or returns how RTS/CTS operates at the main data interface in the form x,
where:
0 = RTS/CTS Loop, No Action
RTS and CTS are looped, so that CTS echoes the state of RTS, but RTS
does not control the ON/OFF state of the carrier
1 = Loop, RTS Controls Tx O/P
RTS and CTS are looped, so that CTS echoes the state of RTS, and RTS
controls the ON/OFF state of the carrier (in other words, the modem will not
bring up its TX carrier until RTS is asserted.)
2 = Ignore RTS, Assert CTS
3 = 1:N system in use.
RTS/CTS ignored (Query only) RTS is ignored, and CTS is asserted
unconditionally.
Example: <0/RTS=0 (RTS/CTS Loop, No Action).
RTS=
RTS?
RTS*
RTS#
RTS?
RTS=x
(see Description of
Arguments)
DoubleTalk
Carrier-in-
Carrier (CnC)
Mode
CNM=
1 byte,
value of
0 to 9
Command or Query.
Valid only in CDM-570A Compatible Mode (CMO=1).
Sets or returns CnC Mode in the form x, where:
0 = Off
1 = On (normal)
2 = APC, C-Band, Side A
3 = APC, X-Band, Side A
4 = APC, Ku-Band, Side A
5 = APC, Ka-Band, Side A
6 = APC, C-Band, Side B
7 = APC, X-Band, Side B
8 = APC, Ku-Band, Side B
9 = APC, Ka-Band, Side B
CNM=
CNM?
CNM*
CNM#
CNM?
CNM=x
(see Description of
Arguments)
