CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Serial-based Remote Product Management 8–31 MN-CDM570A
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
Outdoor Unit
Comms Enable
ODU=
1 byte,
value of 0 or 1
Command or Query – CDM-570A Only.
Enables or disables communications, via the FSK link, with a Comtech EF Data
transceiver (ODU) in the form x, where:
0 = Disabled
1 = Enabled
Example: <0/ODU=0 (ODU disabled)
ODU=
ODU?
ODU*
ODU#
ODU?
ODU=x
(see Description of
Arguments)
IP Address
IPA=
18 bytes,
numerical
Command or Query.
Sets or returns the IP address and network prefix for the ‘10/100 M&C’ 10/100
BaseT Ethernet management port, in the form xx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address
yy is the network prefix (from 8 to 30)
Example: <0/IPA=010.006.030.001.24
IPA=
IPA?
IPA*
IPA#
IPA?
IPA=
xxx.xxx.xxx.xxx.yy
(see Description of
Arguments)
IP Gateway
IPG=
15 bytes
numerical
Command or Query.
Sets or returns the IP Gateway Address for the Ethernet management port, in the
form aaa.bbb.ccc.ddd, where permitted ranges (all zeroes are not permitted) are:
aaa = 0–223
bbb = 0–255
ccc = 0–255
ddd = 0–255
Example: <0/IPG=010.006.030.001
IPG=
IPG?
IPG*
IPG#
IPG?
IPG=
xxx.xxx.xxx.xxx
(see Description of
Arguments)
MAC Address
N/A
12 bytes,
Alphanumerical
Query only.
Returns the unique MAC Address for the modem.
Example: <0/MAC?
>0/MAC=0006B00001C2
N/A
MAC?
MAC=aabbccddeeff
(see Description of
Arguments)
