Serial Interface Operation Revision 3
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
8–31
Parameter Type
Controller-to-Target
Instruction Code and
Qualifier
Arguments for
Command or
Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 to 57)
Target-to-Controller
(see Description of Arguments)
Command Query
Response to
Command
Response to
Query
Re Center Buffer
RCB=
N/A
1 byte
Command only.
Force the software to recenter the receive buffer.
s=Interface Slot, where:
1=Slot 1
2=Slot 2
EXAMPLE: <0/RCB=2 (re-centers the buffer on the Slot 2 interface card)
RCB=
RCB?
RCB#
RCB*
N/A
PIIC Rx ASI Mode
PRM=
PRM?s
1 byte
Command or Query.
(ASI PIIC only) Sets or returns Rx ASI Mode in the form sx, where:
s=Interface Slot, where:
1=Slot 1
2=Slot 2
x=Mode, where:
0=Off
1=ASI-Normal
PRM=
PRM?
PRM#
PRM*
PRM=x
PIIC Tx ASI Mode
PTM=
PTM?s
1 byte
Command or Query.
(ASI PIIC only) Sets or returns Tx ASI Mode in the form sx, where:
s=Interface Slot, where:
1=Slot 1
2=Slot 2
x=Mode, where:
0=Off
1=ASI-Normal
2=ASI- Advanced
PTM=
PTM?
PTM#
PTM*
PTM=x
PIIC Rx ASI
Framing
PRF=
PRF?s
1 byte
Command or Query.
(ASI PIIC only) Sets or returns Rx ASI Framing in the form sx, where:
s=Interface Slot, where:
1=Slot 1
2=Slot 2
x=Framing, where:
0=None
1=TS-188
2=TS-204
PRF=
PRF?
PRF#
PRF*
PRF=x
PIIC Tx ASI
Framing
PTF=
PTF?s
1 byte
Command or Query.
(ASI PIIC only) Sets or returns Tx ASI Framing in the form sx, where:
s=Interface Slot, where:
1=Slot 1
2=Slot 2
x=Framing, where:
0=None
1=TS-188
2=TS-204
PTF=
PTF?
PTF#
PTF*
PTF=x
