Serial Interface Operation Revision 3
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
8–32
Parameter Type
Controller-to-Target
Instruction Code and
Qualifier
Arguments for
Command or
Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 to 57)
Target-to-Controller
(see Description of Arguments)
Command Query
Response to
Command
Response to
Query
PIIC Rx ASI Data
Rate
PRD=
PRD?s
10 bytes, numeric
Command or Query.
(ASI PIIC only) Sets or returns Rx ASI Data Rate, in kbps, in the form dddddd.ddd:
EXAMPLE: <0/PRD=1210000.000 (sets Slot 1 PIIC Rx ASI Data Rate to 210Mbps)
PRD=
PRD?
PRD *
PRD #
PRD=dddddd.d
dd
PIIC Tx ASI Data
Rate
PTD=
PTD?s
10 bytes, numeric
Command or Query.
(ASI PIIC only) Sets or returns Tx ASI Data Rate, in kbps, in the form dddddd.ddd:
EXAMPLE: <0/PTD=1210000.000 (sets Slot 1 PIIC Tx ASI Data Rate to 210Mbps)
PTD=
PTD?
PTD *
PTD #
PTD=dddddd.dd
d
PIIC Rx ASI Output
Format
PRO=
PRO?s
1 byte
Command or Query.
(ASI PIIC only) Sets or returns Rx ASI Output Data Format in the form sx, where:
s=Interface Slot, where:
1=Slot 1
2=Slot 2
x=Format, where:
0=Normal Stream
1=Burst Output
PRO=
PRO?
PRO#
PRO*
PRO=x
PIIC Tx ASI
Restamping
PTR=
PTR?s
1 byte
Command or Query.
(ASI PIIC only) Sets or returns Tx ASI PCR Restamping in the form sx, where:
s=Interface Slot, where:
1=Slot 1
2=Slot 2
x=PCR Restamping control, where:
0=Disable
1=Enable
PTR=
PTR?
PTR#
PTR*
PTR=x
