16.2.10 Setting Up an Alarm Buzzer
The SMP Gateway has a normally closed relay that can be used to trigger an output. If you install
a buzzer on the relay’s output, you can configure the Annunciator to trigger the buzzer upon
alarm.
Note: To locate the relay’s output on the SMP Gateway’s back panel, refer to the
SMP 16 Installation Guide.
To activate this feature:
 In SMP Config, from the tree view, select the General branch under the Annunciator
instance.
 Select the checkbox under Close Relay Contact on Alarm.
16.2.11 Temporarily Deactivating the Annunciator
For some reasons, you might want to deactivate the Annunciator, without losing its configuration.
To do so:
 In SMP Config, from the tree view, select the General branch under the Annunciator
instance.
 Select the checkbox under Disabled.
To reactivate the Annunciator later, just clear the Disabled checkbox.
16.3 Setting Up the Touch Screen
Now that you have completed the Annunciator setup, you are ready to connect and calibrate the
touch screen.
Note: Cooper Power Systems recommends the use of a touch screen from Elo
TouchSystems for use with the SMP Gateway.
16.3.1 Connecting the Touch Screen to the SMP Gateway
Two cables are usually provided with a touch screen:
 A video cable.
This cable should be connected to the VIDEO connector of the SMP Gateway and to the
video input connector of the screen.
