150 • SMP Gateway User Manual
A cable to convey screen-touching information.
When a touch screen is used with a computer, the screen also acts as a mouse when its user
touches it. The touch information is transmitted using either a USB or serial cable.
Note: If you have trouble connecting these cables to the SMP Gateway, refer to the
SMP 16 Installation Guide.
The use of a USB cable is recommended, as the SMP Gateway will detect it automatically: no
configuration is required. Just connect the USB cable to the screen and to one of the USB port of
the SMP Gateway.
If you must use a serial cable, follow these steps:
Connect the serial cable to the screen and to one of the serial port of the SMP Gateway. You
can use any port you like, except the Console port located on the front panel of the
SMP Gateway.
Start SMP Manager.
Select your SMP Gateway from the list.
From the Tools menu, click SMP Config.
Follow the procedure described in the “Configuring the Serial Port Interfaces” section, page
34, to specify the appropriate interface
(ELO Touchscreen) for the selected serial port.
16.3.2 Setting Up a Screen Saver using SMP Config
Your touch screen may have an energy saving feature, but you can also configure the Annunciator
to enter a screen saver mode during periods of inactivity.
To set up the Annunciator’s screen saver:
In SMP Manager, select your SMP Gateway.
From the Tools menu, select SMP Config.
In SMP Config, from the tree view, select Annunciator, then your Annunciator instance,
then the General branch.
Under Screen Saver Wait Time, select the inactivity time to wait before the Annunciator
enters screen saver mode. You can also turn off this feature by selecting No Screen Saver.
16.4 Uploading the Configuration to the
SMP Gateway
Before you can use the Annunciator, two steps are left. You must:
upload the configuration file to the SMP Gateway and restart the system;
