208 • SMP Gateway User Manual
Step To do this Follow these steps:
13. In the Maximum speed drop-down list, select 115200 bps.
14. Clear the Enable hardware flow control checkbox. Click OK.
15. Click the Networking tab, and then click Settings.
16. In the PPP Settings dialog box, clear the Enable LCP extensions
checkbox, the Enable software compression checkbox, and the
Negotiate multi-link for single link connections checkbox. Click
OK.
17. Under This connection uses the following items, clear the Client
for Microsoft Networks checkbox.
18. Click Internet Protocol (TCP/IP), and click Properties.
19. In the Internet Protocol (TCP/IP) Properties dialog box, click
Advanced.
20. In the Advanced TCP/IP Settings dialog box, clear the Use default
gateway on remote network checkbox and the Use IP header
compression checkbox. Click OK three times.
21. Close the Connect <Connection Name> dialog box.
4
Configure
SMP Manager to
communicate
with the
SMP Gateway
1. Start SMP Manager. Select the SMP Gateway to be configured and
from the File menu, click SMP Gateway Properties.
2. In the Gateway Properties dialog box, type a significant name for
the new SMP Gateway, such as “SMP Gateway direct connection”.
3. If you have an SMP 4-20 or an SMP 8-40:
Type 100.100.100.1 in the First IP Address box.
Type 100.100.100.2 in the Second IP Address box.
If you have an SMP 4 or an SMP 16:
In the First IP Address box, type the IP pool starting address
that you specified when you installed your SMP Gateway (see
your SMP Gateway’s installation guide on the SMP Gateway
Software & Tools CD-ROM).
Do not type anything in the Second IP Address box.
4. Click Add.
The PC will communicate with the SMP Gateway using the address(es)
specified here.
22.2 Windows 2000 Setup Procedures
If the SMP Tools run under Windows 2000, use the procedures outlined in this section to:
Setup a dial-up (modem) connection between the PC and the SMP Gateway.
Setup a direct serial connection between the PC and the SMP Gateway.
