SMP Gateway User Manual • 205
Step To do this Follow these steps:
6. Insert the installation CD for the modem driver, if you have one.
7. In the Found New Hardware Wizard dialog box, choose whether
you want Windows to install the driver automatically or from a
specific location and click Next.
8. Once Windows advises you that it has installed the driver, click
Finish.
9. Click Finish to close the Add Hardware Wizard dialog box.
10. Click OK to close the Phone and Modem Options dialog box.
3
Set up a new
dial-up (modem)
connection for
the
SMP Gateway
Perform this step for each SMP Gateway with which you want to
communicate via modem.
1. From Windows’ Start menu, access the Control Panel.
2. Double-click Network Connections.
3. Double-click New Connection Wizard.
4. In the New Connection Wizard dialog box, click Next.
5. Select Connect to the network at my workplace and click Next.
6. Select Dial-up connection and click Next.
7. If your PC is only equipped with a single modem, skip this step.
Otherwise, select the modem you want to use for this connection, and
click Next.
8. Type a descriptive name for the connection and click Next.
9. Type the phone number you will dial to connect to the SMP Gateway
and click Next.
10. If your PC is not equipped with a smart card slot, skip this step.
Otherwise, the wizard will ask you if you want the use a smart card
to log you into the remote network. Select the option that suits you
the most and click Next (by default, the Do not use my smart card
option is selected).
11. Under Create this connection for, select Anyone’s use, click Next
and click Finish.
12. In the Connect <Connection Name> dialog box, click Properties.
13. From the General tab, select the modem you want to use for this
connection and click Configure.
14. In the Modem Configuration dialog box, select the Enable
hardware flow control checkbox, the Enable modem error control
checkbox and the Enable modem compression checkbox.
15. Click the Networking tab, and then click Settings.
16. If you are using an SMP 4-20 or an SMP 8-40:
In the PPP Settings dialog box, clear the Enable LCP extensions
checkbox, the Enable software compression checkbox, and the
Negotiate multi-link for single link connections checkbox. Click
OK.
If you are using an SMP 4 or an SMP 16:
In the PPP Settings dialog box, select the Enable LCP extensions
