210 • SMP Gateway User Manual
Step To do this Follow these steps:
3
Set up a new
dial-up (modem)
connection for
the
SMP Gateway
Perform this step for each SMP Gateway with which you want to
communicate via modem.
1. From Windows’ Start menu, click Settings, and then click Control
Panel.
2. Double-click Network and Dial-up Connections.
3. Double-click Make New Connection.
4. In the Network Connection Wizard dialog box, click Next.
5. Select Dial-up to private network. Click Next.
6. Type the phone number you will use to dial the SMP Gateway. Click
Next.
7. Under Create this connection, click For all users. Click Next.
8. Type a descriptive name for the connection. Click Finish.
9. In the Connect <Connection Name> dialog box, click Properties.
10. In the General tab, click Configure.
11. In the Modem Configuration dialog box, select the Enable
hardware flow control checkbox, the Enable modem error control
checkbox and the Enable modem compression checkbox.
12. Click the Networking tab, and then click Settings.
13. If you are using an SMP 4-20 or an SMP 8-40:
In the PPP Settings dialog box, clear the Enable LCP extensions
checkbox, the Enable software compression checkbox, and
Negotiate multi-link for single link connections checkbox. Click
OK.
If you are using an SMP 4 or an SMP 16:
In the PPP Settings dialog box, select the Enable LCP extensions
checkbox and the Enable software compression checkbox, and clear
the Negotiate multi-link for single link connections checkbox.
Click OK.
14. Under Components checked are used by this connection, clear the
Client for Microsoft Networks checkbox and the File and Printer
Sharing for Microsoft Networks checkbox.
15. Click Internet Protocol (TCP/IP), and click Properties.
16. In the Internet Protocol (TCP/IP) Properties dialog box, click
Advanced.
17. In the Advanced TCP/IP Settings dialog box, clear the Use default
gateway on remote network checkbox and the Use IP header
compression checkbox. Click OK three times.
18. Close the Connect <Connection Name> dialog box.
4
Configure
SMP Manager to
communicate
with the
SMP Gateway
1. In SMP Manager’s File menu, click Add SMP Gateway.
2. In the Gateway Properties dialog box, type a significant name for
the new SMP Gateway, such as “SMP Gateway via modem”.
3. If you have an SMP 4-20 or an SMP 8-40:
