SMP Gateway User Manual • 213
Step To do this Follow these steps:
4
Configure
SMP Manager to
communicate
with the
SMP Gateway
1. From SMP Manager’s File menu, click Add SMP Gateway.
2. In the Gateway Properties dialog box, type a significant name for
the new SMP Gateway, such as “SMP Gateway direct connection”.
3. If you have an SMP 4-20 or an SMP 8-40:
 Type 100.100.100.1 in the First IP Address box.
 Type 100.100.100.2 in the Second IP Address box.
If you have an SMP 4 or an SMP 16:
 In the First IP Address box, type the IP pool starting address
that you specified when you installed your SMP Gateway (see
your SMP Gateway’s installation guide).
 Do not type anything in the Second IP Address box. Click
Add.
The PC will communicate with the SMP Gateway using the address(es)
specified here.
