232 • SMP Gateway User Manual
Data Point Name Description
Local Control
_smp___setLocalControl This binary output point allows you to switch from local
control (by a local HMI, such as Visual Substation), to
remote control (by the SCADA). _smp___localControl
indicates the current control state of the SMP Gateway.
_smp___localControl If set to 1, this binary input point indicates that the
SMP Gateway is actually controlled locally, by Visual
Substation or another HMI. If the gateway is currently
controlled by the SCADA, this point is set to 0. At the
SMP Gateway’s startup, this point is set to 0.
_smp___restartSystem This binary output point allows you to restart the
SMP Gateway.
_smp___setNOrelay
(available on SMP 16)
This binary output point allows you to open and close the
SMP Gateway’s normally open (NO) relay.
_smp___stateNOrelay indicates the actual state of the relay.
_smp___stateNOrelay
(available on SMP 16)
This binary input point indicates the actual state of the
SMP Gateway’s normally open (NO) relay. If set to 1, the
relay is closed.
Security
_smp___securityAccountLocked This binary input point shows if there is an account locked on
the SMP Gateway.
Remote Access
_smp___dialupEnable This binary output point allows you to accept or block all
incoming RAS dialup connections to the SMP Gateway. Set
it to 1 to accept all incoming RAS dialup connections.
_smp__dialupEnabled indicates the resulting state.
_smp___dialupEnabled This binary input point indicates if all incoming RAS dialup
connections to the SMP Gateway are accepted of blocked. If
set to 1, all connections are accepted.
_smp___dialupInUse This binary input point indicates whether or not there is
actually communication in progress via an incoming RAS
dialup connection.
Passthrough
(for each passthrough connection named “<connection>”)
_smp___<connection>Enable This binary output point allows you to lock or unlock the
passthrough connection. Set it to 0 to lock the connection.
_smp___<connection>Enabled indicates if the connection is
locked or not.
_smp___<connection>Enabled This binary input point indicates the passthrough
connection’s lock state. If set to 0, the connection is locked
and cannot be used.
