Installation
Install the thermostat in the cover.
Install a new gasket on the thermostat housing.
Install thethermostat cover and four mounting capscrews.
Tighten the capscrews.
Torque Value: 47 N•m [35 ft-lb]
Install the CELECT™ coolant temperature sensor into the
thermostat housing.
Torque Value: 34 N•m [25 ft-lb]
Install the thermostat housing assembly and mounting
gasket on the rocker lever housing and onto the water
transfer tube.
Install the four mounting capscrews and washers.
Tighten the capscrews.
Torque Value: 47 N•m [35 ft-lb]
Install the upper radiator hose and the air compressor
coolant return line to the thermostat housing.
Tighten all hose clamps.
Torque Value: 5 N•m [40 in-lb]
Section 1 - Cooling System Thermostat Housing (1-30)
N14 Page 1-67
