Engine Removal (9-01)
NOTE: Place a tag on all hoses, lines, linkage, and electrical
connections as they are removed to identify their locations
on the engine.
Disconnect the battery cables.
Drain the engine coolant. Refer to Procedure 1-07.
NOTE: If the coolant is not going to be reused, dispose of
used coolant or antifreeze in accordance with federal, state,
and local law and regulations.
Drain the lubricating oil. Refer to Procedure 2-06.
Disconnect the starter cable, the engine ground straps,
the cab or chassis to engine hoses, the tubing, the elec-
trical wires, and the hydraulic lines.
NOTE: Dispose of used oil in accordance with federal, state,
and local law and regulations.
Disconnect the intake and the exhaust air pipes.
Disconnect all chassis mounted ‘‘engine driven’’
accessories.
Engine Removal (9-01) Section 9 - Engine Remove and Install
N14Page 9-4
