Operate the engine until the oil temperature stabilizes.
The temperature must be between 82°C [180°F] and
93°C [200°F].
Observe the oil rifle pressure as the oil temperature rises.
Observe the oil pressure at the oil main rifle. The pressure
must be as follows:
Oil pressure at idle (minimum allowable) 70 kPa [10 psi]
at 93°C [200°F].
At no load governed speed: 240 to 310 kPa [35 to 45 psi].
If the pressure is within these specifications, the lubri-
cating system is operating properly.
Lubricating Oil Cooler Assembly (2-19)
Removal - Assembly
Drain the cooling system. Refer to Procedure 1-07.
Disconnect the battery.
NOTE: If the coolant is not going to be reused, dispose of
used coolant/antifreeze in accordance with federal, state,
and local laws and regulations.
Remove the turbocharger oil supply tube, the bypass
filter return tube, the turbocharger drain tube, and the
turbocharger.
Remove the oil filter and the coolant filter.
Section 2 - Lubricating System Lubricating Oil Cooler Assembly (2-19)
N14 Page 2-49
