Install the lubricating oil pump in the mounting hole in the
cylinder block gear flange.
Install the five mounting capscrews. Tighten the cap-
screws.
Torque Value: 54 N•m [40 ft-lb]
Install the DFC signal line. Tighten the signal line tube
nuts.
Torque Value: 14 N•m [120 in-lb]
Install the lubricating oil transfer tube. Refer to Procedure
2-11.
Confirm that the oil level in the oil pan is to the full mark.
Operate the engine until the water temperature reaches
82°C [180°F]. Check the oil pressure, and check for oil
leaks.
High Lubricating Oil Pressure Relief
Valve (2-14)
Removal
Remove the lubricating oil pump. Refer to Procedure
2-13.
Remove the lubricating oil pump cover.
High Lubricating Oil Pressure Relief Valve (2-14) Section 2 - Lubricating System
N14Page 2-34
