Cleaning and Inspection - Lubricating Oil
Filter Head
Clean all gasket surfaces.
NOTE: Do not allow dirt or gasket material to get into the oil
passages.
Cleaning and Inspection - Lubricating Oil
Filter Bypass Valve
Clean the poppet valve spring, plunger, and retaining
plug.
Inspect the o-ring on the retaining plug for cuts or tears.
Replace the o-ring if damaged.
Inspect the teflon o-ring on the poppet valve for wear,
cuts, or tears. Replace the complete poppet valve if there
is any damage.
Lubricating Oil Cooler Assembly (2-19) Section 2 - Lubricating System
N14Page 2-54
