Engine Mounts Inspection (9-02)
Inspect all rubber-cushioned mounts for cracks or dam-
age.
Inspect all mounting brackets for cracks or damaged bolt
holes.
NOTE: Damaged engine mounts and brackets can cause
the engine to move out-of-alignment, can damage the drive-
line components in the equipment, and can result in vibra-
tion complaints.
Engine Installation (9-03)
Install all accessories and brackets that were removed
from the previous engine.
Installation such as short and medium nose conventional
chassis, the factory installed rear engine lifting brackets
are usually removed due to space constraints. In this
case, the portable rear engine lifting bracket, Part No.
3823835, will be required to install the engine into the
chassis. Follow instructions for the rear engine service
lifting bracket installation in Procedure 9-01.
NOTE: If the rear engine mounts are attached to the trans-
mission, it may be necessary to install the engine and the
transmission as an assembly.
Section 9 - Engine Remove and Install Engine Mounts Inspection (9-02)
N14 Page 9-9
