Install the intake and exhaust pipes to the turbocharger
and tighten the clamps.
Torque Value: 8.5 N•m [75 in-lb]
Operate the engine and check for air leaks.
Turbocharger Replacement (3-08)
Removal
Remove the oil supply and the oil drain tubes from the
turbocharger.
Remove the intake and the exhaust pipes from the
turbocharger.
Loosen the clamp on the CAC pipe connection.
Remove the four turbocharger mounting nuts.
Remove the turbocharger and discard the gasket.
NOTE: If the turbocharger mounting nuts do not turn off
freely, split the nuts to avoid breaking a mounting stud.
Section 3 - Combustion Air System Turbocharger Replacement (3-08)
N14 Page 3-17
