Remove the test equipment.
Turbocharger Blade Damage (3-06)
Checking
Remove the intake and the exhaust pipes from the
turbocharger.
Visually inspect the turbocharger compressor impeller
blades for damage.
Rebuild or replace the turbocharger if damage is found.
Refer to Procedure 3-08.
If the compressor impeller is damaged, inspect the intake
air piping and the filter element for damage.
NOTE: Repair any damage before operating the engine.
Turbocharger Blade Damage (3-06) Section 3 - Combustion Air System
N14Page 3-14
