Turbocharger Turbine Housing V-Band
Clamp Capscrew 3-01 8.5 N•m 75 in-lb
Turbocharger Intake Air Pipe Clamps 3-01 8.5 N•m 75 in-lb
Turbocharger Mounting Nuts 3-08 44 N•m 32 ft-lb
Turbocharger Oil Drain Line Mounting
Capscrews 3-08 44 N•m 32 ft-lb
Turbocharger Oil Supply Line Mounting
Capscrews 3-08 30 N•m 22 ft-lb
Component Specifications and Torque Values Section V - Engine Component Specifications
Page V-14 N14
Component or Assembly (Procedure) Ref.No./Steps Metric U.S.
