AccuVision
®
AV6010 Long-Range Camera System Manual Chapter 8 137
08-AV6010_Troubleshooting_R10.doc Accu-Sort Systems, Inc.
AV6010 Image Viewer
The AV6010 Image Viewer is a real-time application tool for viewing the
camera sensor data. (Remember, AV6010 uses a high-speed linear sensor,
it does not ‘take a picture’ like a typical camera.) This tool allows you to view
what the sensor is currently seeing. It also displays any embedded data for
diagnostic and set up purposes.
CAUTION: The AV6010 Image Viewer is for setup and diagnostic
purposes only. It should not be allowed to remain running while a camera
system is under normal operating conditions as it changes the line rate and
turns on the illumination to capture the sensor data.
NOTE: The AV6010 Image Viewer is not an image storage application. If
image storage and retrieval are needed, the VisionCapture/IDS (Image
Depot Server) System is an option available from Accu-Sort.
