80 Setup AccuVision
®
AV6010 Long-Range Camera System Manual
Accu-Sort Systems, Inc. 05-AV6010_Setup_R10.doc
Camera Mounting
Use the Camera Mounting window to make adjustments to the orientation,
mounting position and front/back box tracking extensions.
NOTE: It is recommended that the AV6010 Install Wizard be used to set
these parameters the first time. Through a series of setup wizards, you
can ‘teach’ the system key parameters which results in auto calibration.
The Camera Mounting window can be used to adjust the dimensions as
necessary to improve system performance.
Prerequisites:
The AV6010 Install Wizard should be downloaded and installed on your
computer.
Use the Camera Install Wizard to auto-calibrate these configuration
settings.
To set the Camera Mounting configuration:
1. Select Setup > Mounting from the menu tree. Select the camera
position that you want to configure (e.g., front, top, back, etc.). The
window for the selected camera position is displayed.
NOTE: Only the camera positions applicable to your system and assigned
in the System Configuration window will have a Camera Mounting
window selectable from the menu tree. The position selected will appear at
the top of the active screen area in ( ) brackets.
2. Enter the Camera Pitch Angle.
3. Enter the Camera Yaw (0 or 180).
4. Enter the Distance from Trigger (X).
5. Enter the Camera Offset (Y).
6. Enter the Mounting Height (Z).
7. Confirm the Far Working Distance.
8. Enter the length for the front and back Tracking Box Extensions.
9. Click Update to save any changes.
10. Click Reset to return all parameters to the last values saved.
See also: Mounting > Camera Mounting in Appendix B.
