Datalogic Accu-Sort AccuVision AV6010 User Manual

148 Specifications AccuVision
®
AV6010 Long-Range Camera System Manual
Accu-Sort Systems, Inc. A1-AV6010_Specifications_R10.doc
Power Consumption Estimates
3-Camera Tunnel 4-Camera Tunnel 5-Camera Tunnel 6-Camera Tunnel
Device Volt-amps
Each Unit
Qty.
Extended
Volt-amps
Qty.
Extended
Volt-amps Qty.
Extended
Volt-amps Qty.
Extended
Volt-amps
AV6010 Camera System
42" [107 cm]
405
3
1215 4 1620 5 2025 6 2430
AV6010 RangeFinder 23
1
23 1 23 1 23 1 23
Network Switch 23 0 0 1 23 1 23
VisionCapture / IDS 288 0 0 1 288 1 288
LCD Monitor 87 0 0 1 87 1 87
FAST Monitor 175 0 0 0 0
Total Power Consumption (Volt-amperes)
1238
1643 2446 2851
Single-phase current 115 VAC
10.8
14.3 21.3 24.8
230 VAC
5.4
7.1 10.6 12.4
NOTE: Inrush current is approximately 15 times the running current.
RangeFinder Dimensions
